Settings

7.1 Adjusting the hose diameter
(only for dust class M)
Set the hose diameter setting [1-10] to the
connected hose diameter.
This ensures that the airspeed in the suc-
tion hose is measured correctly.
7.2 Connecting electric power
tools
WARNING
Risk of injury
Observe the maximum connected loads
for the appliance socket (see chapter
"Technical data").
Make sure that the power tool is switched
off before connecting or disconnecting.
Connect the electric power tool to the ap-
pliance socket [1-3].

7.3 Adjusting the suction power

You can use the suction power adjuster [1-8]
to adapt the machine suction power to dif-
ferent applications.

7.4 Applying the brake

Folding out the black brake lever [1-14]
prevents the mobile dust extractor from
rolling. To achieve this, lift the front end of
the mobile dust extractor slightly and push
the black brake lever downwards until it
latches into place. Push the lever [1-13]
again to release.

7.5 Temperature cut-out

To prevent overheating, a temperature cut-
out switches the mobile dust extractor off
when it reaches a critical temperature.
► Switch off the mobile dust extractor and
allow to cool for about 5 minutes.
If the mobile dust extractor will not switch
on again, please contact a PROTOOL service
workshop.
18
7.6 Changing the fi lter bag
Removing the fi lter bag [3]
Open the locking clips [2-2] and remove the
top section of the machine [2-1].
Remove the fi lter bag.
Dispose of the used fi lter bag in accordance
with statutory regulations.
Clean the dust container [2-3].
Inserting the fi lter bag [4]
Insert a new fi lter bag in the inlet port of
the dust container and interlock it.
Important: be aware that the locking en-
gages.
Replace the top section [2-1] and close the
locking clips [2-2].
► Make sure that the fi lter bag is not pinched
between the top and bottom sections.

7.7 Changing the disposal bag

Removing the disposal bag [5]
Close off the extractor opening [1-1] using
the sealing plug [1-15] (standard equip-
ment for VCP 260/480 M).
Open the locking clips [2-2] and remove the
top section of the machine [2-1].
Close the disposal bag.
Remove the disposal bag.
Dispose of the used disposal bag in accord-
ance with statutory regulations.
Clean the dust container [2-3].
Inserting the disposal bag [6]
Insert a new disposal bag on the inlet noz-
zle of the container and lock in position.
Important: The lateral openings on the dis-
posal bag must be positioned inside the con-
tainer. Make sure that the bolt engages.
Place the disposal bag over the edge of the
container.
Make sure that the contacts [9-2] are
free.
Replace the top section [2-1] and close the
locking clips [2-2].
