Fronius Datamanager Bedienungsanleitung Seite 97

*)
*) WLAN can only be selected if Fronius Datamanager is equipped with WLAN.
Select the type of internet connection (LAN or WLAN) (1)
4
Click on "Save" (2)
5
After the changes have been loaded, the "Changes have been applied" message ap-
pears.
Click on "OK"
6
The internet connection data is displayed
IMPORTANT! Depending on which internet connection you have selected, a gateway
and a DNS server must be entered for the relevant interface.
If, for example, a LAN internet connection was selected, a gateway and a DNS server
must be entered for the LAN interface.
Click on "LAN" or "WLAN" in the "Network" submenu depending on the network con-
7
nection interface you are using.
The settings for the LAN or WLAN interfaces are displayed.
(1)
(2)
95
