Pfannenberg PA X 1-05 Betriebsanleitung Seite 7

Approvals
Approvals (valid for marked equipment)
Construction Product
PA 1: VdS 0786-CPD-21182
Directive
(89/106/EWG)
PA1: G 212115, PA X 1-05: G 212188
VdS
Data see Construction Product Directive (89/106/EWG)
GLxxxxx (in preparation)
GL
Environmental Category C, H, EMC1
PA 1
UL, cUL
PA 1
PA X 1-05
PATROL-Sounders PA 1 comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules.
UL/ cUL specifications:
Suitable for indoor and outdoor use. Signaling area: see document 30303-005-1.
Cable gland entries:
Conduit installation needs to be UL/ cUL listed fittings suitable for knockout openings. The supply wiring has to be enclosed in metal con-
duits for products for Fire Alarm Use.
According to CSA-C22.2 No. 205-M1983 clause 4.3.4 the connection is limited to max. three leads.
Installation:
The units shall be installed indoors or outdoors in accordance with the manufacturer's installation instructions as well as the National Electri-
cal Code (NFPA 70) and the National Fire Alarm Code (NFPA 72) for the units evaluated for Public Fire Alarm applications in the U.S. In
Canada, they shall be installed in accordance with the Canadian Electrical Code, Part 1 and the Standard for the Installation of Fire Alarm
Systems CAN/ULC-S524-M91 for the units evaluated for Public Fire Alarm applications. The installation shall also be in a manner accept-
able with the local authority having jurisdiction.
For audible application for Fire Alarm Service use both terminals for connection. Break wire run to provide Electrical Supervision (see UL
464 clause 39.1e). The tone no. 111 is to be used for evacuation use only
(see UL 464 clause 39.1e)
cUL directional characteristics for
the horn:
Min. Output sound pressure
level: [dB(A)]
Connecting cables:
985 501 000
Options
Rated voltage
Operating voltage range
acc. to EN54-3, EN54-23
Lens colours of beacon
Tone
2
15
60
104
131
146
Signaling area
Environmental
protection class
Installation position
The test was performed using the provided diaphragm nipples and the outer fixing holes.
Rated
Voltage
24V – 48V DC
(Fire Alarm Equipment)
12V – 48V DC
(General Signal
Equipment)
24V AC
115V AC
230V AC
AXIS
Horizontal
Horizontal
Vertical
Vertical
Type
PA 1-24 DC
Tone no. 2, 15, 60, 104, 131, 146, 111, 112, and 113 was used for this test.
7 [0.28"]
solid
PA X 1-05: 0786-CPD-21220
PA 1
24 – 48V DC
18V – 57V
Option: -SSM (18V – 30V)
-
Compliant with the Construction Product Directive (89/106/EWG)
1200Hz-500Hz (Saw tooth) DIN/PFEER P.T.A.P.
500Hz-1200Hz (Slow whoop)
825Hz (Continuous)
660Hz (Intermittent tone)
800Hz/ 1000Hz (Alternating tone)
544Hz/ 440Hz (NF S 32-001)
EN54-3:
see document 30303-005-1
arbitrary
Audible-signal Appliance
Fire Alarm Equipment
ULSZ, ULSZ7
x
Special application, limited oper-
ating voltage range 18 – 57V DC
-
-
ANGLE
32 deg. left or right
28 deg. left or right
32 deg. left or right
28 deg. left or right
Voltage UL 464 db(A) at 10 ft ++
18V DC 77,1 (for tone 113)
7 [0.28"]
stranded
PA X 1-05
–SSM
24V DC 48V DC
18 - 30V 40 - 57V
red, clear
EN 54-23 Category O:
see document 30303-005-1
Type B
Light faces down
Audible and Visual signal Appliance
General Signal Equipment
UCST, UCST7 and UEES, UEES7
x
x
In preparation
dBA
-3
-6
-3
-6
CAN/ULc-S525-07
86,2 (for tone 60)
7
