1.2 Now you are ready to fly!
Recording
Your Element will automatically detect your take-off and begin recording
flight data. REC will appear at the top of the display screen. In flight, the
display screen shows you the most useful information.

Information display

GPS signal
Battery charge
Compass rose
Analogue vario
Airspace
Time / ALT3 / QNH
F1
Route / Waypoint
8 First flight
Altitude
(ALT1 or ALT2)
Integrated vario
Wind direction
Ground speed
Last thermal
Flight
information display
Scroll with the arrow keys
between various
information displays, e.g.
graphic altimeter
F2
ESC / On / Off
ALT 1 gives your altitude above Mean Sea Level. It is automatically calibrated by GPS.
Ground speed is given in kilometres per hour, knots, or miles per hour.
The compass rose shows your direction of flight by indicating the relative position of
True North with the symbol N. You are always flying toward the top of the compass
rose.
Last thermal shows the relative position of your last climb. If you need to return to
that thermal, turn your glider so that the indicator appears at the top of the compass rose.
Airspace shows the direction to the nearest airspace. (Feature coming soon!)
The analogue vario shows your vertical speed (climb or sink) in metres per second,
ranging from +10 m/s to -10 m/s. You may also choose feet per minute, ranging from
+20 fpm x100 to -20 fpm x100.
Vario 3.2 m/s
The integrated vario gives your vertical speed averaged over the last five seconds.
Wind direction is shown once you have flown a few 360s. Your Element will
automatically calculate the wind direction from your drift and show it as a small wind
arrow to the right of the compass rose.
When landing, keep the wind arrow pointing down. That means you are
flying into wind.
English
5.0 m/s 6.8 m/s
First flight 9
