Air regulator (Fig. 3/29)
The air regulator (29) can be fitted between the
suction hose (9) and the suction tube (17). The
suction power of the nozzle can be infinitely adjusted
using the air regulator (29).
When wet vacuuming, make selective use of the air
regulator to suck in air as well as liquids. This will help
to take some strain off the equipment when
vacuuming liquids.
5.5 Suction nozzles
Dual-purpose nozzle (Fig. 3/14)
The dual-purpose nozzle (14) is for vacuuming solids
and liquids over medium to large areas.
Various attachments can be fitted to the combination
nozzle depending on what you sort of work you wish
to carry out:
Wet vacuuming
Use the attachment for wet vacuuming (Fig. 3/26).
Vacuuming smooth flooring
Use the attachment for smooth floors (Fig. 3/27).
Vacuuming carpets
Use the attachment for carpets (Fig. 3/28).
Fit the appropriate attachment into the combination
nozzle (14) from underneath and secure it to the
combination nozzle (14) using the side lugs (fig. 15).
Ensure that the attachments are perfectly secure.
Crevice nozzle (Fig. 3/23)
The crevice nozzle (23) is designed for vacuuming
solids and liquids in corners, edges and other areas
that are difficult to access.
Upholstery nozzle (Fig. 3)
The upholstery nozzle (26) is specially designed for
vacuuming solids on upholstery and carpets.

6. Operation

6.1 ON/OFF switch (Fig. 2/7)
Switch position 0:
Switch position I:
Switch position AUTO:
12
6.2 Dry vacuuming
Use the pleated filter (24) for dry vacuuming (see
point 5.2). The dirt bag (27) can be fitted in addition
when removing particularly stubborn dirt (see point
5.3).
Always ensure that the filters are perfectly secure.
6.3 Wet vacuuming
For wet-vacuuming, use the foam filter (25) (see point
5.2).
Check that the filter is securely fitted at all times.
Water drain screw (Fig. 1/11)
To make the tank (10) easier to empty after wet
vacuuming, it is fitted with a water drain screw (11).
Open the water drain screw (11) by turning it anti-
clockwise and drain the liquid.
When wet vacuuming, the floating safety switch (21)
closes when the maximum tank level is reached. In
doing so, the suction noise of the equipment will
change and become louder.
You must then switch off the equipment and empty
the tank.
The wet and dry vacuum cleaner is not suitable for
the vacuuming of combustible liquids.
For wet vacuuming, use only the supplied foam filter.
6.4 Automatic mode
Connect the power cable on your electric tool to the
automatic socket-outlet (4) and connect the suction
hose (9) to the extractor connector on your electric
tool. Check that the connections are secure and air-
tight.
You can use the supplied electric tool adaptor (22) to
connect the suction hose (9) to the electric tool. To do
so, fit it between the suction hose and the extractor
port on the electric tool.
Set the switch (7) on the wet and dry vacuum cleaner
to position AUTO, automatic mode. The moment you
switch on the electric tool, the wet and dry vacuum
Off cleaner switches on as well. When you switch off the
Normal operation electric tool, the wet and dry vacuum cleaner
Automatic mode switches off as well after a pre-set delay.
6.5 Blowing
Connect the suction hose (9) to the blow connector
(19) on the wet and dry vacuum cleaner.
Important!
Important!
