Transmitter features
1. Keypad.
2. LCD.
3. Removable accessory tray.
4. D-cell battery tray.
5. Rechargeable battery pack
(Optional).
Transmitter keypad
6. Power key : Switches the unit on
and off. Opens the transmitter menu.
7. Frequency key
Menu navigation key.
8. Up and down arrows
the output signal. Scrolls through the
menu options.
9. Measure key : Opens a sub menu.
Used to take voltage and impedance
measurements.
: Selects frequency.
: Adjusts
Transmitter screen icons
10. Battery icon: Indicates the battery level.
11. Alphanumeric description of selected
operation mode.
12. Standby icon: Appears when the
transmitter is in Standby mode.
13. Output level: Displays transmitter
output power.
14. Clamp icon: Indicates when a clamp or
other plug is connected.
15. DC icon: Appears when the transmitter
is powered from a DC source.
16. Induction indicator: Appears when the
transmitter is in Induction mode.
17. A-Frame (Tx-5 and Tx-10 only):
Indicates when the transmitter is in
Fault-Find mode.
18. CD Mode indicator (Tx-10 only):
Indicates that the transmitter is in
Current Direction mode. For use with
RD8000 locators only.
™
19. Voltage warning indicator: Indicates
that the transmitter is outputting
potentially hazardous voltage levels.
20. Volume icon: Displays the volume level.
21. Pairing icon (Tx-5B and Tx-10B only):
For use with RD8000 locators only.
22. Bluetooth icon (Tx-5B and Tx-10B only).
For use with RD8000 locators only.
