Locator features
1. Keypad
2. LCD with auto backlight
3. Speaker
4. Battery compartment
5. Battery charger connector
6. Accessory connector
7. Headphone connector
8. Bluetooth module antenna
®
9. Marker loop antenna
Locator keypad
10. Power key : Switches the unit on
and off. Opens the locator menu.
11. Frequency key
Closes submenu.
12. Up and down arrows
the signal gain. Scrolls through the
menu options.
13. Antenna key : With antenna folded
up, toggles peak, combined peak/
null and null (PLM and TLM models)
modes. With antenna folded down,
toggles marker and combined
(marker/line) modes. Opens a
submenu.
14. Graph key : Saves SurveyCERT
measurements.
15. Transmitter key
Locator screen icons
16. Indicates the signal strength and peak
marker.
17. Signal strength: Numerical indication
of signal strength.
18. Peak / Proportional arrows: Indicates
the location of the line relative to the
locator.
19. Battery icon: Indicates the battery level.
20. Volume icon: Displays the volume level.
: Selects frequency.
: Adjusts
: Not used.
21. Fault-Find arrows (PLM and TLM
models only).
22. Radio Mode: Indicates when Radio
Mode is active.
23. Power Mode: Indicates when Power
Mode is active.
24. Accessory or Measurement indicators:
Indicate when an accessory is
connected or if measurements are
active
25. A-Frame icon: Indicates when the
A-Frame is connected.
26. Operating mode indicator.
27. Bluetooth icon: Indicates status of
Bluetooth connection. Flashing icon
means pairing is in progress. Solid icon
indicates an established connection is
active.
28. Antenna mode icon: Indicates antenna
selection: Peak, Null and combined
Peak/Null.
29. Sonde icon: Indicates that the signal
source is from a sonde (DLM, PLM and
TLM models).
30. Line icon: Indicates that the signal
source is from a line.
31. Compass/Marker mode indicator:
Shows the direction of the located
cable relative to the locator. Also used
as a graphical indication for Marker
mode active
32. Current /depth indicator.
