PIN ASSIGNMENTS

BNC Separate SYNC
H/CS Horizontal
VS Vertical
R Red
G Green
B Blue
Composite SYNC Sync on Green
Composite SYNC No Connection
No Connection
Red
Green
Blue
A - 1
No Connection
Red
Green with SYNC
Blue
