3.1 Parent unit
1 Sound indicator:
– flashes slowly if the baby unit is only
picking up low-level sounds
– flashes quickly if the baby unit is
picking up loud noises
2 Charging indicator:
– gives off a steady light when the parent
unit is switched on
– does not give off any light when the
parent unit is switched off and the
batteries are not charging
– flashes slowly
seconds) when
charging
– flashes quickly (approx. every second)
when the batteries are about to run out.
3 Range indicator:
– gives off a steady light when the parent
unit is within receiving range of the
baby unit

4.1 Baby monitor

Power supply for parent unit
and baby unit:
Power:
Protection class:
Radio frequency:
Range:
Batteries for parent unit:
Parent unit operating life using batteries:
Battery charging time in parent unit:

3. Parent unit/baby unit

(approx. every 4
the batteries are

4. Technical data

5 V DC / 0.6 A
3 W
III
2.4 GHz (permitted in all EU countries.
In France, Italy, Russia and Ukraine
permitted solely for domestic use)
up to 50 m indoors,
up to 200 m outdoors.
2x AAA / 1.2 V / 600 mAh / NiMH
max. 6 hours
max. 15 hours
12
– flashes when the parent unit is not
close enough to the baby unit to
guarantee
transmission
4 Belt clip (removable)
5 Mains adapter connector socket
6 Battery compartment cover
7 Parent unit
8 On/off button
– press down for 3 seconds to turn on
– press down for 5 seconds to turn off
9 Increase volume
10 Reduce volume
11 Speaker
3.2 Baby unit
12 Mains adapter connector socket
13 Baby unit
14 Mains adapter indicator
– illuminated when the mains adapter is
connected and the baby unit is ready
for use
15 Microphone
interference-free
