Supplementary documentation for the Operating Instructions
Proline Promag 10/50/51/53W, 55S
Supplementary information for devices with flanges,
nominal diameter DN 50 (2") and hard rubber lining
This supplementary documentation is valid for the following documentations:
• Operating Instructions Proline Promag 10
• Operating Instructions Proline Promag 50
• Operating Instructions Proline Promag 51
• Operating Instructions Proline Promag 53
• Operating Instructions Proline Promag 55
Affected measuring devices
This supplementary documentation is valid for the following devices:
• Measuring device:
• Nominal diameters: DN 50 (2")
Tightening torques
Nominal diameter
[mm] Pressure rating [bar]
50
Nominal diameter
[mm] [inch]
50 2"
50 2"
Nominal diameter
[mm]
50
50
Nominal diameter
[mm]
50
Nominal diameter
[mm]
50
SD145D/06/a2/07.10
71114927
→
→
→
→
→
Promag 10W, 50W, 51W, 53W, 55S
EN (DIN)
Threaded fasteners
PN 40
ANSI
Pressure rating Threaded fasteners
[lbs]
Class 150
Class 300
JIS
Pressure rating Threaded fasteners
10K
20K
AS 2129
Pressure rating Threaded fasteners
Table E
AS 4087
Pressure rating Threaded fasteners
PN 16
BA082D
BA046D, BA055D
BA137D
BA047D, BA052D, BA053D, BA117D
BA119D, BA124D, BA126D
Max. tightening torque [Nm]
4 × M16
Max. tightening torque
[Nm]
4 × 5/8" 35
8 × 5/8" 18
Max. tightening torque [Nm]
4 × M16
8 × M16
Max. tightening torque [Nm]
4 × M16
Max. tightening torque [Nm]
4 × M16
Hard rubber
48
Hard rubber
[lbf · ft]
26
13
Hard rubber
40
20
Hard rubber
32
Hard rubber
32
