DMX512 ADRESS
3.3
In ADDRESS menu the DMX-adress is set.
MENU
ADDRESS
3.4 AUTOPROGRAMS
In AUTO the 6 preprogrammed Auto-Programms can be selected
and in SPEED mode the programspeed is set.
MENU
AUTO
3.5 STATIC MODE
In COLOR menu the fixture can be controlled manually by dimming
three individual segments (0 - 255).
MENU
COLOR
3.6 TEST MODE
In TEST LED the fixture can be testet by dimming the full fixture at
once or checking the nine individual segments.
MENU
TEST LED
001-512
MODE 1
AUTO MODE 1
MODE 2
AUTO MODE 2
MODE 3
AUTO MODE 3
MODE 4
AUTO MODE 4
MODE 5
AUTO MODE 5
MODE 6
AUTO MODE 6
W1/RED
0-255
W2/GREEN
0-255
W3/BLUE
0-255
ALL ON
W1/R1 ON
W2/R2 ON
W3/R3 ON
W4/G1 ON
W5/G2 ON
W6/G3 ON
W7/B1 ON
W8/B2 ON
W9/B3 ON
