IP camera Instructions
GB GB

Configuration and set-up

configuration and set-up
2.

2.1. Preparation

▸
Connect the IP camera to a 100 Mbit
Ethernet LAN
▸ Power supply via Power over Ethernet (PoE)
or suitable power supply unit

Connection via Ethernet

The IP camera is set up as a DHCP client, i.e. it
obtains its IP address from a DHCP server. Use
Axis Camera Management Software to locate and
set-up existing cameras within your network.
The camera's factory default IP address is:
192.168.0.90

2.2. Scope of applications

1. Using the IP camera with a PC and the Behnke
IP video software
separate instructions on IP video Software
configuration. IP video Software and the cor-
responding manuals can be found here:
www.behnke-online.de/downloads/software
2. Using the IP camera as a surveillance camera
▸ Follow the instructions of your existing
video management system to add an
"Axis M 3045" type camera.
*
Where the camera is used as a stand alone model without connection to a Behnke SIP door
intercom system (please cf. model types on page 21), the camera requires class 1 PoE. Where the
camera is used in connection with a Behnke SIP door intercom system (please cf. model types on
page 21), the camera requires class 0 PoE.
24
▸ Please have a look at the

2.3. User name and password

User name: root
Password: Admin
*
2.4. Access your video feed via a web
browser
Accessing the video feed:
e.g. "http://<user>:<password>@<ip-addr>/
axis-cgi/mjpg/video.cgi?resolution=1920x1080"
Additional options can be found within the doc-
umentation on the VAPIX interface provided by
AXIS. Please note that your web browser needs
to support the corresponding video formats.
It may be necessary to contact your network
administrator.
Please note: Not suited for continuous video
feed broadcasting.
