GB
■
Take long breaks during your
working day so you can re-
cover from the noise and the
vibrations. Plan your work in
such a way that the use of ap-
pliances that generate strong
vibrations is spread over sev-
eral days.
■
If you notice an unpleasant
sensation or discolouration of
the skin on your hands when
using the appliance, stop work
immediately. Take sufficient
work breaks. Without suffi-
cient breaks, a hand/arm vi-
bration syndrome can occur.
■
Minimise your risk of being
exposed to vibrations. Main-
tain the appliance according
to the instructions in the oper-
ating instructions.
■
If the appliance is used fre-
quently, contact your dealer to
purchase anti-vibration ac-
cessories (e.g. handles).
■
Avoid working with the appli-
ance at temperatures below
10 °C. Define how the vibra-
tion load can be limited in a
work plan.

3.7.3 Noise pollution

A certain level of noise exposure
from this appliance is inevitable.
Carry out noisy work at ap-
proved and specified time peri-
28
ods. Observe rest periods as ne-
cessary and restrict the duration
of the work to a minimum. For
your personal protection and
protection of persons in the vi-
cinity, appropriate hearing pro-
tection must be worn.

4 INSTALLATION AND START-UP

WARNING!
Danger of cutting injur-
ies
Danger of cutting injuries
when reaching into sharp-
edged, moving appliance
parts and into cutting tools.
■
Before maintenance,
care and cleaning work,
always switch off the
appliance. Remove the
rechargeable battery.
■
Always wear protective
gloves during mainten-
ance, care and cleaning
work.
4.1

Installing the guard plates (02, 03, 04)

Attach the main plate (02)
1. Insert (02/a) the main plate (02/1) on the cut-
ter head (02/2).
2. Hook (02/b) the fastening clip (02/3) and
screw in (02/c) the fastening screw [M6]
(02/4).
Attach the front guard plate (03)
1. Place both halves (03/1, 03/2) of the front
guard plate on the cutter head and push to-
gether (03/a). The edge of the front guard
plate has to be located under the main plate.
2. Screw in (03/b) both screws [ST4*16] (03/3).
Installation and start-up
BCA 4030
