Power Parameter
Input Voltage
Charging Current
Discharging Curent
Charging Power
Balancer Current
Compensating Current
Balancer-Tolerance
Charging Capacity
Pb Battery Voltage
Weight
Dimensions

Key Features

MODE
Batt. Type / Stop button. Press this key to enter the main menu or to get out of the menu you last selected. Likewise, this
key is used to perform a setting action or the abort current loading / unloading process.
+ AND –
Increase / decrease button. You can increase or decrease certain parameter values or choose between different informa-
tion with the arrow keys during the load / unload process.
ENTER/START
Select / Enter button. This confirms the desired setting or starts your chosen process.
20
DC 11.0~18.0V
AC 110V or 230V
A 10,0 A (max. 2x100W)
A 2,0 A (max. 2x 10W)
W max. 100Wx2
A 300mA
mA 400mAh
V ±0.01V
NiCd/NiMH 1~15 cells
LiPo, LiIon, LiFe 1-6 cells
V 2~24V
g 1050g
mm 230mm*155mm*42mm
MODSTER 200 Charger Duo
