Englische Bezeichnung - Nordic 50 ELLIPTICAL Benutzerhandbuch

42 Hinge bolt L/R
NR.

ENGLISCHE BEZEICHNUNG

43 Wave washer
44 Powder spacer
45 Nylon locknut M8
46 Bushing
47 U connected tube
48 Crank w/pulley
49 Allen bolt M8*50
50 Flat washer
51L/R Nut L/R
52 Crank R
53 Sensor wire lower
54 Sensor wire middle
55 Magnet holder plate
56 Magnet holder
57 Magnets
58 Allen bolt M8*55
59 Crank cover
60L/R Chain cover L/R
61 Self-tapping screw ST5*15
62 Self-tapping screw ST3*10
63 Adjustor assembly
64 France nut
65 C clip
66 Axle for flywheel
67 Bearing 6001
68 Bearing 6901
69 Flywheel
70 Hex head bolt M6*25
71 Hex head nut M6
72 Sensor bracket
73 BB assembly
74 Belt
75 Self-tapping ST5*15
76 Spring
77 Pully
78 Hand pulse sensor
79 Washer
80 Screw ST4*20
81 Hand pulse wire lower
82 End cap for wire
83 Sensor wire
4
1/1
Anz.
2
4
3
6
2
1
2
2
1/1
1
1
1
1
1
8
1
2
1/1
12
4
2
2
2
1
1
1
1
1
2
1
1
1
4
1
1
2
2
2
2
1
1
