EN
ADDITIONAL FUNCTIONS
Automatic shut-off
If no button is used for 20 min. the instrument will power off automatically.
Sound
Switch the sound function on. The instrument will now show by a sound signal if the horizontal or
vertical position approaches. The closer the position is the denser the sound signal will be.
If the instrument is in correct vertical or horizontal position the sound will be continuous.
Mode functions [1) - 5)]
1) Slope indication in ° (14,5°)
2) Slope indicaton in % (25,9 %)
3) Indication IN/FT (3 1/8 IN/FT)
4) Indication IN/FT (3,10 IN/FT)
5) Indication mm/m (258,9 mm/m)
Keep the mode button pressed to have all mode functions switch fast. The display will not show any
values. Release the mode button to return to the standard indication.
CONNECTION TO CAMERA TRIPOD
With 1/4"-thread (at the bottom side) S-Digit multi + can be connected to a camera tripod.
SPECIAL FEATURE WITHIN THE RANGE OF 0° - 90°
O-setting in any position required:
In the range between 0° and 90° the ZERO layer can be defined in any position.
Start the calibration function in the position required (press CAL longer than 3 sec.) -
wait 3 sec. - press CAL again - wait 3 sec. - press CAL again - finalized.
Do not turn the S-Digit multi + during this process.
Now the ZERO layer is defined in the new position and the application required can be started.
ATTENTION:
We recommend to define the ZERO layer in the horizontal position again when you have finished your
application. Otherwise it may happen that for the following measurements the results can be complete-
ly wrong (e.g. when you work the next day or if another user is working with the unit).
14
S-Digit multi_DE-EN-FR.indd_Korr..indd 14-15
SAFETY NOTES
SPECIFIC REASONS FOR ERRONEOUS MEASURING RESULTS
Measurements through glass or plastic windows; dirty laser emitting windows; after the instrument has been dropped
or hit. Please check the accuracy.
Large fluctuation of temperature: If the instrument will be used in cold areas after it has been stored in warm areas (or
the other way round) please wait some minutes before carrying out measurements.
CARE AND CLEANING
Handle measuring instruments with care. Clean with soft cloth only after any use. If necessary damp the cloth with
some water. If the instrument is wet clean and dry it carefully. Pack it up only if it is perfectly dry. Transport in original
container / case only.
ELECTROMAGNETIC ACCEPTABILITY (EMC)
It cannot be completely excluded that this instrument will disturb other instruments (e.g. navigation systems); will be
disturbed by other instruments (e.g. intensive electromagnetic radiation nearby industrial facilities or radio transmit-
ters).
CE-CONFORMITY
The instrument has the CE-mark according to EN 61326:1997 , EN 55022, EN 61000-4-2/-3.
WARRANTY
This product is warranted by the manufacturer to the original purchaser to be free from defects in material and
workmanship under normal use for a period of two (2) years from the date of purchase. During the warranty period,
and upon proof of purchase, the product will be repaired or replaced (with the same or similar model at manufacturers
option), without charge for either parts or labour. In case of a defect please contact the dealer where you originally
purchased this product. The warranty will not apply to this product if it has been misused, abused or altered. Without
limiting the foregoing, leakage of the battery, bending or dropping the unit are presumed to be defects resulting from
misuse or abuse.
EXCEPTIONS FROM RESPONSIBILITY
1.
The user of this product is expected to follow the instructions given in the user manual. Although all instruments
left our warehouse in perfect condition and adjustment the user is expected to carry out periodic checks of the
product's accuracy and general performance.
2.
The manufacturer, or its representatives, assumes no responsibility of results of a faulty or intentional usage or
misuse including any direct, indirect, consequential damage, and loss of profits.
3.
The manufacturer, or its representatives, assumes no responsibility for consequential damage, and loss of profits
by any disaster (earthquake, storm, flood etc.), fire, accident, or an act of a third party and/or a usage in other
than usual conditions.
4.
The manufacturer, or its representatives, assumes no responsibility for any damage, and loss of profits due to
a change of data, loss of data and interruption of business etc., caused by using the product or an unusable
product.
5.
The manufacturer, or its representatives, assumes no responsibility for any damage, and loss of profits caused
by usage other than explained in the user' manual.
6.
The manufacturer, or its representatives, assumes no responsibility for damage caused by wrong movement or
action due to connecting with other products.
EN
E
15
07.03.2014 10:01:27
