Pail Holder
Pail
REPLACING THE COMMODE
ARMRESTS (FIGURE 3)
1. Remove the Phillips Tap Screws, two (2)
each from the underside of the arm tube(s).
2. Lift armrest(s) from the arm tube(s).
3. Install/reinstall the armrest(s).
Commode Seat
Seat
Clamp
Back Frame Rail
Armrest
Phillips Tap
Screws
5
6
4
10
PARTS LIST
ITEM
DESCRIPTION
1.
Rubber Tip
2.
Leg Extension
3.
Anti-Rattle
4.
Screw
5.
Back Tube Assembly
6.
Wing Nut
7.
Nylock Nut
8.
Toilet Seat with Lid
10.
Pail with Lid
11.
Splash Shield
12.
2-piece Desk Length Armrest
13.
Snap Button
14.
Release Spring
2
8
12
13
4
7
7
14
3
2
1
11
QTY.
4
4
4
4
1
2
4
1
1
1
2
4
4
