TROUBLE SHOOTING TABLE
No or unusual Y signal
Is there Y signal input at pin (84) of
IC4502?
Yes
Is there Y signal output at pin (7) of
IC4501?
Yes
Is there Y signal output at pin (5) of
IC4311?
Yes
Check SC4303 and its peripheral
circuits.
http://www.pureglare.com.au
(Continued)
No
Check IC4502 and its peripheral
circuits.
No
Check IC4501 and its peripheral
circuits.
No
Check IC4311 and its peripheral
circuits.
39
XG-P20XU
XG-P20XE
XG-P20XD
