2. Removing the Intake cover and lamp unit.
2-1. Detach the intake cover.
2-2. Loosen the screw and slide the lamp cover out of position.
2-3. Remove the three screws and lift the lamp unit out of position.
3. Removing the rear body.
3-1. Remove the six screws off the terminal board at the back.
3-2. Remove the six screws and detach the rear body.
Lamp Unit
3-2
3-1
3-2
2-3
Rear Body
http://www.pureglare.com.au
2-1
Intake Cover
Lamp Cover
13
XG-P20XU
XG-P20XE
XG-P20XD
2-2
