H60.0.xx.xC-01
1 General Note
Read this document carefully and get used to the operation of the device before you use it.
Keep this document within easy reach near the device for consulting in case of doubt.
Mounting, start-up, operating, maintenance and removing from operation must be done by qualified, specially trained
staff that have carefully read and understood this manual before starting any work.
The manufacturer will assume no liability or warranty in case of usage for other purpose than the intended one, ignor-
ing this manual, operating by unqualified staff as well as unauthorized modifications to the device.
The manufacturer is not liable for any costs or damages incurred at the user or third parties because of the usage or
application of this device, in particular in case of improper use of the device, misuse or malfunction of the connection
or of the device.
The manufacturer is not liable for misprints.
2 Intended Use
The BaleCheck 200 is a complete set for material moisture measuring including an handheld in-
strument (GMH 3830) with moisture display and rating.
The slim and robust measuring probe (GSF 40 TF) makes the set a first-class tool for humidity
measurements of pressed straw or hay (bales) and grain.
The measuring probe included to the set is connected to the device by a BNC-plug and Thermo-
couple plug.
Depending on the application either the material moisture u (based on dry matter) or the water con-
tent w (based on wet total mass) can be displayed.
Please consider the information "Measuring precision" in chapter 5.4
3
Product Specification
3.1 Scope of supply
The set includes:
Measuring probe GSF 40 TF
Handheld meter GMH 3830 incl. 9V battery and Operating Manual
Protection bag ST-KR
Operating Manual Appendix BaleCheck 200
3.2 The measuring probe GSF 40 TF
isolator
probe tip with
temp. sensor
probe tube
100
minimum immersion
Operating Manual Appendix BaleCheck 200 with GMH 38
_____________________________________________________
_____________________________________________________________________________
page 2 of 4
