How It Works; Description Of The Device - Compex Fit Gebrauchsanweisung

You are strongly advised to read carefully the contraindications and safety
measures described at the start of this manual in Chapter 1 prior to using
your stimulator.

Description of the device

A
B
On/Off button
A
"i" button used for:
B
• Immediate access to information displays (illustrations of electrode
placement or explanations of the programs)
• Increasing stimulation energies in several channels simultaneously
Sockets for the 4 stimulation cables
C
Stimulation cables
D
Channel 1 = blue
Channel 3 = yellow
+/- buttons for the 4 stimulation channels
E
Socket for the charger (Slide the red cover to the right to free the charger
F
connector)
Battery compartment
G
H Belt clip socket
1 2 3 4
Channel 2 = green
Channel 4 = red
