Thank you!
Thanks for your purchase of the Infinity VS8
and your confidence in us.
Parts of the appliance
Fig. 1:
1 "Carpet/hard floor" switch
2 Suction hose release catch
3 Telescopic tube catch
4 Bypass vent
5 Motor protection filter cover catch
6 Dust container release catch
7 Cable retraction button
8 Parking bracket
9 On/Off switch
10 Exhaust filter cover release catch
Fig. 2:
1 Floor nozzle (standard)
* optional accessories:
2 *parquet brush:
for vacuuming delicate surfaces
(e. g. laminate, parquet)
3 *Turbo brush:
for thoroughly deep cleaning of carpets with
the rotating brush head
Fig. 3:
1 "Carpet/hard floor" switch
for deep- and short-pile carpets,
runners
for hard floors, e.g. laminate, tiles,
PVC, etc.
Fig. 4:
1 2-in-1 combi nozzle (loosely packed in the
carton) (see also Fig. 5)
2 Crevice nozzle (loosely packed in the
carton)
Fig. 5:
The 2-in-1 combi brush can be used as:
1 Furniture brush
2 upholstery nozzle,
you only have to remove the
3 brush attachment
as shown.

Technical data

Type of : Cyclone cylinder vacuum
appliance cleaner
Model : Infinity VS8 Loop
[M5035/0-9; M5038/0-9]
Voltage : 220-240 V ~ 50 Hz
Power : 1.400 W nom - 1.600 W max
Dust : approx. 1.5 litres
container
capacity
Filters : Dual motor protection filter
(washable), exhaust filter
Power cord : approx. 6 m
length
Weight : approx. 5.5 kg
Technical and design specifications may be
changed in the course of continuous product
improvement.
© Royal Appliance International GmbH
Infinity VS8 Loop
1

Safety notices

1.1 Re: Operating Manual
Read this operating manual completely before
working with the appliance.
Keep the operating manual for reference.
Include the operating manual if you pass the
appliance on to someone else.
Non-compliance with these instructions
can lead to serious injuries or damage to
the appliance.
We take no responsibility for damages due to
violations of these operating instructions.
1.2 Re: The Notices Given
Important notes for your safety are especially
marked. Always observe these notices to avoid
accidents and damage to the appliance.
WARNING:
Warning concerning health hazards
describing possible risks of injury.
ATTENTION:
Warning concerning possible dangers to the
appliance or other objects.
NOTE:
Highlights tips and information for you.
1.3 Re: Children
People (including children) who are unable
to safely operate the appliance on account of
their physical, sensory or mental abilities or
their lack of experience or knowledge should
only use this appliance under surveillance or
instruction by a responsible person. Keep the
appliance out of reach of people of these
groups.
Packing material must not be used to play
with. There is danger of suffocation.
1.4 Re: Appropriate Use
The cylinder vacuum cleaner is intended for
home use only. It is not suitable for commercial
use.
Use the cylinder vacuum cleaner only for
cleaning normally soiled floors, rugs and
curtains.
Any other use is considered inappropriate and
is prohibited.
It is especially forbidden:
To vacuum-clean:
- Hair, fingers and other parts of the body.
They could be sucked in and injured.
- Pieces of clothing (e. g. shoe laces,
scarves, etc.). They could be sucked in
and cause injuries.
- water and other fluids, especially damp
carpet cleaning agents. Moisture inside
the appliance can cause a short-circuit.
- Toner dust (for laser printers, copying-
machines, etc.) There is danger of fire or
explosion.
- hot ash, burning cigarettes or matches.
This could cause a fire.
Safety notices
- pointed objects such as glass shards,
nails, etc. Such objects destroy the filters.
- Construction rubble. plaster, cement,
finest drilling-dust, makeup, etc.
The filters may clog, causing damage to
the appliance.
To use the appliance near explosive or
easily flammable substances. There is danger
of fire or explosion.
Outdoor use. There is danger of rain and
dirt destroying the appliance.
Sticking objects into the appliance's
openings. It could overheat.
1.5 Re: Power supply
The appliance runs on electricity -- that
means there is a general risk of electric shock.
So please especially observe the following:
- Never touch the plug with wet hands.
- Always pull directly at the plug if you want
to disconnect the appliance from the
mains. Never pull the power cord, it might
break.
- Take care that the power cord is not bent,
pinched, rolled over or gets in contact
with heat sources.
- Only use extension cords of a capacity
sufficient for the power requirement of the
appliance.
- Never immerse the appliance in water or
other liquids. Keep it away from rain and
moisture.
- Only operate the appliance if your mains
voltage is the same as that indicated on
the appliance's nameplate. Wrong
voltage can destroy the appliance.
1.6 If the appliance is defective
Never use a defective appliance or operate
an appliance with a defective power cord. If the
power cord of this appliance is damaged it
must be replaced by the manufacturers, their
authorised service representative or a similarly
qualified person to avoid danger.
Refer a defective appliance to
authorised dealer or the Royal Appliance
service for repair. Address: page 13,
„Warranty".
an
