Bedienungsanleitung / User manual VTC-512D
5. Pulse control
4 pins: 2 pairs with jumper
6. Output terminal
24 hour sabotage protection
7. Power input 12 V DC
Standby current: 3 mA
Current in working mode: 28 mA
_________________________________________________________________________________
Position 1:
For instant reaction if a movement is detected.
Position 2:
For twice detections within 15 seconds.
N.C. (Normally Closed):
1. For connection to a security device.
2. 24 hour sabotage protection.
N.O. (Normally Open):
Max. relay charge: 1 A, 125 V AC; 2 A, 30 V DC
Note:
The detector is activated by motions caused by
people and not by fixed objects. Don't expose the
detector to direct sunlight or other reflecting
surroundings.
