Direct voltage indication
(Contact via metal probe and contact electrode)
Direct voltage testing on the conducting UUT
surface can be carried out by selecting position 3
(different to contact-free voltage detection).
For this purpose, place the metal probe onto the
measurement spot whilst touching the contact
electrode.
Switch-
Position
Pos. 1
Pos. 2
Pos. 3
Measuring
Indirect
(contactless)
Indirect
(contactless)
Direct
(metal probe
and Contact
electrode)
Principal Function
Position
Contactless voltage
detection
LED is blinking and sig-
nal is audible!
Torch function is active
Contactless voltage
detection
LED is blinking and sig-
nal is audible! Torch
function is blinking
Contacting voltage
testing
LED is blinking signal is
audible. Torch function is
blinking. Continuity is
active (UUT must be vol-
tage free)
