Connecting upper and lower part
As shown in Fig 5
WARNING! This device consist of two parts, upper
part And lower part. Each part has its own connector.
The upper part contains the female connector. The male
connector was built in the lower part.
To join them together:
1.) Align the arrow on the female connector with raised
ribs on the male connector.
2.) Push them together as deep as possible.
3.) Secure the connection by tightening the plastic sleeve
in clockwise direction.
To disconnect:
1.) Lay down the tool on even ground.
2.) Unscrew the plastic sleeve.
3.) Detach the two parts.
Attaching shoulder strap
As shown in Fig 6
Fix the shoulder strap into the lifting lug on the lower rod
of the device. Adjust length of shoulder strap for getting a
comfortable control.
Fig.5
Fig.6
51
Raised rib
Arrow
