2. Scope of delivery

Outdoor HD-SDI 20x PTZ Dome IR
1080p
Quick start
guide

3. Description of the connections

Name
Network Cable
Audio Cable
2-ch Alarm Out
2-ch Alarm Input
RS485 Cables
HD-SDI Video Cable
Power Cable
Power supply unit
CD / user guide on
Gloves
Adapter
CD
Function
No
No function, not used
Alarm output 1 and 2
Alarm input 1 and 2
RS-485 control cable port
Orange: RS-485+
Yellow: RS-485-
HD-SDI video output
24 VAC power supply
17
English
Insulating tape
Installation material
