Danger!
The equipment and packaging material are
not toys. Do not let children play with plastic
bags, foils or small parts. There is a danger of
swallowing or suff ocating!
•
Tile cutting machine
•
Trough (3)
•
Cooling water pump (13)
•
Angle stop (5)
•
Feet (1)
•
Original operating instructions
•
Safety instructions

3. Proper use

The tile cutting machine is designed for the
standard cutting of small and medium-size tiles
(glazed tiles, ceramic tiles or similar) which can
be accommodated by the size of the machine. It
is designed for DIY applications and craft busi-
nesses in particular. It should never be used for
cutting wood or metal.
The machine should be used exclusively for its
intended purpose. No other use is permitted
and the manufacturer will not accept liability for
any damages or injury resulting from any such
use; responsibility rests with the user/operator
in any such case. Only use cutting wheels which
are suitable for the machine. Saw blades should
never be used. Compliance with the safety inst-
ructions, the assembly instructions, and advice
and instructions on operation contained in the
operating instructions also falls under the terms
of intended use. All persons operating or carrying
out maintenance work on the machine must be
acquainted with the above and be aware of all
potential dangers.
In addition, strict compliance with the accident
prevention regulations in force in your area, as
well as all other general rules of health and safety
at work, is imperative. The manufacturer's liability
shall be deemed void if the machine is modifi ed in
any way and the manufacturer shall therefore ac-
cept no liability for any damages arising as a re-
sult of modifi cations. Even if the machine is used
as intended, certain residual risk factors cannot
be completely eliminated. For reasons of design
and the construction of the machine, the following
eventualities are possible:
•
Contact with the diamond cutting wheel whe-
re it is not covered.
Anl_TE_TC_620_U_SPK7.indb 17 Anl_TE_TC_620_U_SPK7.indb 17
GB
•
Contact with the diamond cutting wheel while
it is turning.
•
Defective diamond tips flying off the cutting
wheel.
•
Workpieces or parts of workpieces kicking
back.
•
Damage to hearing if the ear-muffs specified
are not used.
Please note that our equipment has not been de-
signed for use in commercial, trade or industrial
applications. Our warranty will be voided if the
machine is used in commercial, trade or industrial
businesses or for equivalent purposes.

4. Technical data

Motor rating .............................. 900 W S2 30 min
Motor speed ......................................... 2950 rpm
AC motor ....................................... 230 V ~ 50 Hz
Insulation material class .......................... Class B
Protection type ............................................. IP54
Table size ...................................... 610 x 325 mm
Working height: ...................................... 700 mm
Cut length .............................................. 620 mm
Jolly length .............................................. 620 mm
Max. workpiece thickness 90° .................. 30 mm
Max. workpiece thickness 45° .................. 25 mm
Diamond wheel .....................Ø 200 x Ø 25.4 mm
Weight .........................................................34 kg
Danger!
A load factor of S2 30 min (intermittent periodic
duty) means that you may operate the motor
continuously at its nominal power level (900 W)
for no longer than the time stipulated on the spe-
cifi cations label (30 minutes ON period). If you fail
to observe this time limit the motor will overheat.
During the OFF period the motor will cool again to
its starting temperature.
Sound and vibration
The noise emission values were measured in ac-
cordance with EN 61029.
- 17 -
