2 | Installation

The TouchMonitor TM3 units are designed for free positioning on tables,
desks, et. al. A TM3 unit consist of a display unit with 4.3 inch touch screen
and a separate interfacebox featuring many capabilities of connecting.
The connected cable supplies the display unit with power and data.
Power supply for the whole unit is supplied through the +24 V DC con-
nector on the interfacebox. Use with power supply model STD-2427PA,
manufactured by Adapter Technology Co Ltd. (which is the external power
supply unit RTW 1168-R wide voltage power supply, included in TM3 and
TM3-6CH packages).
aTTenTiOn! – Please read before installing:
• Before installing the unit please study the safety instructions and the
information on connection and pin assignment.
• An external overcurrent protective device (2 A max.) shall be installed
when using an external 24 V DC power supply!
• Make sure that the delivered power supply unit is not connected.
• Place the unit at a suited place. The display unit shall positioned secu-
rely on a flat surface. The interface box may be placed corresponding to
the cable length away outside the sight field, e. g. on the bottom behind
a table. Please take care about a good guiding of the connected cable.
• Connect unbalanced signal sources to the RCA connectors. Connect
balanced signal sources to the Sub-D connector. Connect all your
other components to the appropriate connectors. Use the correct stan-
dard connection cables for the components and take care about the
pin assignment described in paragraph 2.2!
• Finally, connect the locking 4-pin low voltage connector of the external
power supply to the +24 V DC connector of the interface box. Con-
nect the external power supply to mains.
• The TouchMonitor will initiate its system startup sequence. After the
boot-up the unit is ready for use.
