activate the teach-in mode. The system LED (J)
starts flashing. Pairing mode remains activated for
3 minutes.
You can manually start the teach-in mode for an-
other 3 minutes by pressing the system LED (J)
briefly using a pointed object (see figure 4).
• Your device will automatically appear in the
Homematic IP app.
• To confirm, please enter the last four digits of the
device number (SGTIN) in your app or scan the
QR code. Therefore, please see the sticker sup-
plied or attached to the device.
• Please wait until teach-in is completed.
• If teaching-in was successful, the system LED
lights up green. The device is now ready for use.
• If the system LED lights up red, please try again.
• In the app, give the device a name and allocate
it to a room.
• Slide the cover from the bottom onto the main
sensor and latch it into place by turning it an-
ti-clockwise.
6.2

Alignment of the weathervane

To enable the definition of the wind direction, the weath-
er sensor must be aligned during the first set-up so that
it is pointing north. To do this, please proceed as follows:
First start-up
