8

Datenmodule

8.1

GSM/GPRS module (GSM6H), type 67-0Z

The GSM/GPRS module functions as transparent communication path
between reading software and MULTICAL® 801 and is used for data reading.
The module includes an external dual-band GSM antenna which must always
be used. The module itself includes a line of light emitting diodes indicating
signal strength which are very useful during installation.
Further details about the GSM/GPRS module appear from data sheet
(DK: 5810627, GB: 5810628, DE: 5810629, SE: 5810630) .
8.2 3G GSM/GPRS module (GSM8H), type 67-0U
Like GSM6H this module functions as transparent communication path
between reading software and MULTICAL® 801 and is used for data reading.
However, this module supports both 2G (GSM/GPRS) and 3G (UMTS) which
makes it applicable in areas with 3G coverage only.
The module requires an external Antenna, which covers both 900 MHz, 1800
MHz and 2100 MHz.
The module itself is itted with a line of light emitting diodes indicating signal
strength which are very useful during installation. Furthermore, it is indicated
whether the module is connected to a 2G or a 3G network. Additional
details about the 3G module appear from data sheet (DK: 58101057,
GB: 58101058, DE: 58101059, FI: 58101061, SE: 58101060) .
8.3

Ethernet/IP module (IP201), type 67-0T

The IP module functions as transparent communication between reading
software and MULTICAL® 801 and is used for data reading. The module
supports both dynamic and static addressing. This is speciied in the order
or selected during subsequent coniguration. The module has no built-in
security and must, therefore, always be used in connection with a irewall or
NAT.
Further details appear from the data sheet (DK: 5810541, GB: 5810542,
DE: 5810543, SE: 5810544) .
