7 Bedienung
7.1 Menüstruktur kennen lernen
Die Menüstruktur des Terminalprogramms ist wie
folgt aufgebaut:
1 Network Configuration
1.1 IP Configuration
1.1.1 IP Address
1.1.2 IP Subnet mask
1.1.3 IP Def. Gateway
1.1.4 Enable/Disable DHCP
1.1.5 Settings Ethernet Port
1.2 SNMP Configuration
1.2.1 Trap Receiver Configura-
tion
1.2.1.1 IP Trap Receiver
1.2.1.2 Enable/Disable
1.2.1.3 IP Trap Receiver
1.2.1.4 Enable/Disable
1.2.1.5 IP Trap Receiver
1.2.1.6 Enable/Disable
1.2.1.7 IP Trap Receiver
1.2.1.8 Enable/Disable
1.2.2 SNMPv1 IP Access
1.2.2.1 SNMPv1 Manager
1.2.2.2 SNMPv1 Manager
1.2.2.3 SNMPv1 Manager
1.2.2.4 SNMPv1 Manager
1.2.2.5 SNMPv1 Manager
1.2.2.6 SNMPv1 Manager
1.2.2.7 SNMPv1 Manager
1.2.2.8 SNMPv1 Manager
1.2.2.9 SNMPv1 Manager
1.2.2.A SNMPv1 Manager
1.2.2.B SNMPv1 Manager
1.2.2.C SNMPv1 Manager
1.2.3 Read Community
1.2.4 Write Community
1.2.5 Enable Auth. Traps
1.2.6 Change SNMP Version
1.2.7 Default SNMPv3 User
Name
1.2.8 Default SNMPv3 Pass-
word
1.2.9 Confirm SNMPv3 us-
mUser/Passw
Basic CMC
1.4.2 IP Addr. CMC (DialIn)
1.4.3 IP Addr. Client (DialIn)
1.4.4 Username (DialIn)
1.4.5 Password (DialIn)
1.4.6 Callback Nr (DialIn)
1.4.7 Enable PPP (Dialout)
1.4.8 IP Addr. CMC (Dialout)
1.4.9 IP Addr. Client (Dialout)
1.4.A Username (Dialout)
1.4.B Password (Dialout)
1.4.C Phone Number (Dialout)
1.4.D Modem type
1.4.E MSN (for ISDN)
1.4.F Modem Baudrate
1.5 SMTP (email) Configuration
1.5.1 IP Addr. SMTP Server
1.5.2 SMTP Server Authentica-
tion
1.5.3 Username SMTP Server
1.5.4 Password SMTP Server
1.5.5 eMail Sender Name
1.5.6 eMail Reply to
1.5.7 eMail upon Unit Messages
1.5.8 eMail Address
1.5.8.1 eMail Address
1.5.8.2 eMail Address
1.5.8.3 eMail Address
1.5.8.4 eMail Address
1.6 Syslog Konfiguration
1.6.1 IP Addr. Syslog Server
1.6.2 IP Addr. Syslog Server
1.6.3 Syslog Facility
1.6.4 Enable Syslog
1.7 System Name
1.8 System Contact
1.9 System Location
1.3 NTP Configuration
1.3.1 Enable NTP
1.3.2 IP Addr. NTP Server 1
1.3.3 IP Addr. NTP Server 2
1.3.4 NTP Offset to UTC
1.3.5 NTP Update Frequency (h) 1.A.5 Change HTTPs Port
1.3.6 Dayl. Saving Time, Begin 1.B Enable FTP
1.3.7 Dayl. Saving Time, End
1.4 PPP Configuration
1.4.1 Enable PPP (DialIn)
2 Sensors
2.1 Sensors
2.1.1 z.B. Temperature Sensor
2.1.1.1 Status
2.1.1.2 Value
2.1.1.3 Setpoint High
2.1.1.4 Setpoint Warning
2.1.1.5 Setpoint Low
2.1.1.6 Message Text
2.1.1.7 Alarm Relay
2.1.1.8 Beeper
2.1.1.9 Trap Receiver 1
2.1.1.A Trap Receiver 2
2.1.1.B Trap Receiver 3
3 General Configuration
3.1 Temperature Unit
3.2 Beeper
3.3 Quit Alarm Relay
3.4 Alarm Relay Options
3.5 Web Access
3.6 Actual Date
3.7 Actual Time
3.8 Check Link
3.9 SMS Configuration
3.9.1 PIN GSM-Card
4 Info Page
5 Default, New Config. Of Sensor Units, File Transfer
5.1 Set General Configuration to
Default
5.2 Sensor Unit Detection
5.3 Serial File Transfer (ZMo-
dem)
Abb. 21 Menüstruktur
Bedienung 7
1.A Security
1.A.1 Change Password User
´cmc´
1.A.2 Change Password User
´admin´
1.A.3 Change HTTP Port
1.A.4 Enable SSL
1.C Cons./Teln. Timeout Minu-
tes
1.D Enable/Disable Telnet
1.E Activate Actual Values
2.1.1.C Trap Receiver 4/Log
2.1.1.D Alarm Reset
2.1.1.E Send SMS
2.1.1.F Send eMail
2.1.2 z.B. Humidity Sensor
2.1.3 not available
2.1.4 not available
2.1.5 Name Sensor Unit
2.1.4 Status of Unit
2.2 Unit 2 not available
2.3 Unit 3 not available
2.4 Unit 4 not available
3.9.2 SMS Service Number
3.9.3 ISDN MSN
3.9.4 ISDN Pre-Dial Number
3.9.5 ISDN Command
3.9.6 SMS upon Unit Message
3.9.7 SMS Phone Numbers
3.9.7.1 SMS Phone Number
3.9.7.2 SMS Phone Number
3.9.7.3 SMS Phone Number
3.9.7.4 SMS Phone Number
5.3.1 Send File to CMC
5.3.2 Receive File from CMC
15
DE
