EX-6030
3. Layout, Connections & LED's

3.1 Layout

1x Serial 9 Pin D-SUB Connector

3.2 Connections

DB 9M:
RJ45 Port:
© Copyright 2017 by EXSYS Vertriebs GmbH. All Rights Reserved
RJ45 Port
Reset Button
Serial 9 Pin D-SUB Connector
Pin Signal
1 DCD
2 RXD
3 TXD
RJ45 Port
Pin Signal Pin
1 BI_DA+ 4
2 BI_DA- 5
3 BI_DB+ 6
17
5V DC Connector for
included Power Supply
Pin Signal
4 DTR
5 GROUND
6 DSR
Signal Pin
BI_DC+ 7 BI_DD+
BI_DC- 8 BI_DD-
BI_DB-
English
Pin Signal
7 RTS
8 CTS
9 —
Signal
