The Serial Interface

All measuring and setting data of the unit can be read and/or changed by means of the serial interface and a suitable
electrically isolated interface adapter (GRS3100 or GRS3105). In order to avoid transmission errors, there are several
security checks implemented.
The following standard software packages are available for data transfer:
-EBS9M
-EASYCONTROL:
In case you want to develop your own software we offer aGMH3000-development package including
- a universally applicable 32bit Windows functions library ('GMH3000.DLL') with documentation that can be used by all
'serious' programming languages.
- Programming examples Visual Basic 4.0, Testpoint (Keithley Windows measuring software)
The following interface functions will be supported:
Channel
1 2 3
x x x
x x x
x x x
x x x
x
x
x
x
x
x x x
x x x
x x x
x x x
x x x
x
x x
x x
x
x
x
x
9-channel software to display the measuring value (channel 1) and the temperature (channel 2)
Universal multi-channel software (EASYBUS-, RS485-, and/or GMH3000- operation possible)
for real-time recording and presentation of measuring data in the ACCESS®-data base format.
Dll-
Name/function
Code
0 Read nominal value
3 Read system status
6 Read min. value
7 Read max. value
12 Read ID-no.
174 Delete min. value
175 Delete max. value
194 Set display unit
195 Set decimal point in display
199 Read meas. type in display
200 Read min. display range
201 Read max. display range
202 Read unit of display
204 Read decimal point of display
208 Read channel count
216 Read offset correction
217 Set offset correction
218 Read corr. factor (1000..1200)
219 Set corr. factor (1000..1200)
240 Reset sensor module
254 Read program identification
H35.0.01.6C-03 page 7 of 8
