GREISINGER GMH 3230 Bedienungsanleitung Seite 11

GMH3230e.03
Displays
Display With Two Sensors Connected:
1
2
Display With One Sensor Connected:
1
Special Displayelements:
1
Pushbuttons
1 2
4
2
3
4
5
1
On/off key
min/max when taking measurements:
2
3
press shortly:
press for 1 sec.: the min. or max. value will be deleted
up/down for configuration:
to enter values, and/or change settings
Tare : (for 'DIF'-display when working with two sensors only)
3
press shortly:
press for 1 sec.: tare function will be deactivated
Set/Menu :
4
press (Set) shortly in case of 2 sensors:
press (Menu) for 2 sec.: configuration will activated
5
Store/Quit:
5
Measurement:
Set/Menu:
1
Main display:
CH1: sensor 1, CH2: sensor 2, DIF: sensor1-sensor2
Secondary display:
2
CH1: sensor 1, CH2: sensor 2, DIF: sensor1-sensor2
The display desired can be selected by pressing the
Main display:
1
CH1: sensor 1, CH2: sensor 2, unit automatically detects
to which socket sensor is connected.
Min/Max/Hold: shows if a min., max.or hold value is
1
displayed in either the main or the secondary display.
Offset-arrow: indicates that zero point offset (offset) is
2
activated
3
Corr-arrow: indicates that correction factor is activated
4
Warning triangle: indicates a low battery
Tare arrow: indicates that tare function is activated (for 'DIF'-
5
display when working with two sensors only)
min. or max. measuring value will be displayed
the difference between CH1-CH2 will be set to zero.
Hold current measuring value ('HLD' in display)
Acknowledge setting, return to measuring.
H35.0.01.6C-03 page 3 of 8
key..
the values displayed (CH1,
CH2, DIF) can be selected
