10 www.electrolux.com
8.4 Building In
min.
55 mm
480 mm
A) supplied seal
B) supplied brackets
CAUTION!
Install the appliance only on
a worktop with flat surface.

9. TECHNICAL INFORMATION

9.1 Cooking zones specification
Cooking zone
Left front
Left rear
Right front
Right rear
For optimal cooking results use
cookware not larger than the diameter of
the cooking zone.
min.
min.
650 mm
100 mm
30 mm
560 mm
B
Nominal Power (Max heat set‐
ting) [W]
1500
2000
1500
2000

8.5 Possibilities for insertion

The panel installed below the hob must
be easy to remove and let an easy
access in case a technical assistance
intervention is necessary.
Kitchen unit with door
A
A) Removable panel
B) Space for connections
Kitchen unit with oven
The electrical connection of the hob and
the oven must be installed separately for
safety reasons and to let easy remove
oven from the unit.
145
180
145
180
30 mm
min 20 mm
A
(max 150 mm)
60 mm
B
Cooking zone diameter [mm]
