Connection with the mains

Connect the device to the mains with the power-plug.
The occupation of the connection-cables is as follows:
Cable Pin
Brown Live
Blue Neutral
Yellow/Green Earth
The earth has to be connected!
If the device will be directly connected with the local power supply network, a disconnection switch with a
minimum opening of 3 mm at every pole has to be included in the permanent electrical installation.
The device must only be connected with an electric installation carried out in compliance with the IEC-
standards. The electric installation must be equipped with a Residual Current Device (RCD) with a maximum
fault current of 30 mA.

OPERATION

After you connected the effect to the mains, the EUROLITE LED Bar 288/5 RGB starts running.

LCD Menu

Press the Encoder and turn it clock-wise to view the following menu options in the LCD Display:
Addr ***
Manual Blue ***
Manual Green***
Manual Red ***
No DMX Auto/Sound/Manual
The sequences follow each other in a continuous loop and appear in reverse when the Encoder is turned
counter clock-wise. Press the Encoder again to confirm the desired menu option.
Note: When not in use for longer than 3 seconds, the LCD display dims automatically and shows „Addr*** if
the DMX connection is still in effect. (***shows DMX addressing).
If the DMX connection no longer exists, the LCD Display shows the current non-DMX mode: Auto, Sound or
Manual.
As soon as a setting is changed, the LCD display shows the last used mode.

DMX-512 control

The wires must not come into contact with each other, otherwise
Please note, the starting address depends upon which controller is being used.
International
L
N
Chase 8 s***f **, Chase 8 s***f **
Chase 7 s***f **, Chase 7 s***f **
Chase 6 s***f **, Chase 6 s***f **
Chase 5 s***f **, Chase 5 s***f **
Chase 4 s***f **, Chase 4 s***f **
Chase 3 s***f **, Chase 3 s***f **
Chase 2 s***f **, Chase 2 s***f **
Chase 1 s***f **, Chase 1 s***f **
the devices will not work at all, or will not work properly.
DMX Mode 8-Group/4-Group/2-Group/1-Group
DMX Mode 3Channel/6Channel
