A. Refrigerator Compartment
1. Lighting
2. Filter in the fan
2a. button of fan
2b. cover of fan
3. Shelves / Shelf area
4. Bottle rack
5. Multi-flow cold air system
6. Cooler compartment (best for meat and fish) or
"Zero Degrees" box (to keep foods fresher for longer)
7. Rating plate with commercial name
8. Fruits and vegetables crisper
9. Crisper divider
10. Reversibility kit
11. Separator
12. Door trays
B. Freezer Compartment
13. Storage baskets for frozen food items
14. Shelve
15. Middle basket (freezing zone)
16. Ice tray and/or cold accumulator
17. Door seals
C. Control panel
Anti-bacterial protection (depending on the model):
- Antibacterial filter in the fan (2)
- Antibacterial additives in the Crisper (8)
- Door seals are made of material able to inhibit bacterial
growth (17)
Notes:
- Depending on the model the number and type of
accessories may vary.
- In case of power failure the cold accumulator helps to
keep optimal storage temperature longer.
- All shelves and door trays are removable.
- The internal temperatures of the appliance depend on
the ambient temperature, frequency of opening the
doors, as well as location of the appliance. Temperature
setting must consider these factors.
- The appliance accessories are not suitable for washing
dishwasher.
- After inserting food, ensure that the freezer
compartment door closes properly.
TO INCREASE STORAGE
The freezer compartment can be used without the
baskets to increase storage and for large products.
You can place the food products directly on the racks.
PRODUCT SHEET
HYDROSENSE SHELVES
(depending on the model)
The special contour of the HydroSense shelves creates a
barrier that contain spills and simplifies cleanup,
preventing liquids from leaking onto shelves below.
HOW TO START THE APPLIANCE
Fit the spacers (if supplied) on the
upper part of the condenser at the
rear of the appliance. After plugging
the appliance to the mains, it starts
the operation automatically. After
starting the appliance, wait at least 4-6 hours before
placing food into the appliance. When the appliance is
connected to the power supply, the display lights up and
all the icons appear on the display for few seconds. The
default (factory) values of the freezer compartment and
refrigerator compartment settings light-up. In the
meanwhile the appliance is working to reach the factory-
set temperature, an acoustic alarm sounds, the
Icon and Freezer Temperature LEDs blink. This indicates
that the appliance has not yet reached the optimal
temperature for storage of foodstuffs. Press the
button to silence the acoustic alarm. The
automatically turned-off as soon as the freezer
compartment reaches a temperature below
-10°C and the Freezer Temperature LEDs stop blinking
and shows the chosen setting.
FAN WITH A BUTTON
The fan improves temperature distribution inside the
refrigerator compartment, allowing better preservation of
stored food. By default, the fan is ACTIVE.
It is advisable to keep the fan active, so that the "6th
Sense Fresh Control" / "Green Intelligence ProFresh"
function can work and also when the ambient air
temperature is above 27 ÷ 28°C or if you perceive drops
of water on the glass shelves or in the severe humidity
conditions.
Note
Do not obstruct the air intake area with food items.
To optimize energy consumption and to guarantee
the right performance at lower ambient temperature
(colder than 18°C) please turn off the fan.
To turn off the fan press the button (2a).
If the appliance has the fan it can be equipped with the
antibacterial filter.
Remove it from the box (found in the crisper drawer
