• When ordering please provide our article number as
well as type and year of manufacture for the product.
6 Technical data
Rated voltage
Rated power consumption
Idle speeds
Pressure vessel volume
Operating pressure
Theo. Suction capability
Effective output rate at 1 bar
Effective output rate at 4 bar
Effective output rate at 7 bar
Protection category
Length of mains connection cable
Max. installation altitude
(above sea level)
Weight
Subject to technical changes!
*Operating mode S1 (continuous operation)
The product can be operated continuously with the speci-
fied power.
**Operating mode S3 (periodic intermediate duty)
The operation consists of a nominal load and standstill
time.
The cycle time is 10 min, the relative duty cycle is 25% of
the cycle time.
WARNING
Noise can have serious effects on your health. If the
machine noise exceeds 85 dB, please wear suitable
hearing protection for you and persons in the vicinity.
The noise and vibration values have been determined in
accordance with EN 62841-1.
Noise data
Sound pressure level L
pA
Measurement uncertainty K
Measured sound power level L
Guaranteed sound power level L
Measurement uncertainty K
The specified noise emission values have been measured
in accordance with a standardised test procedure and can
be used to compare one power tool with another.
The specified device emissions values can also be used
for an initial estimation of the load.
20 | GB
230 V~/
50 Hz
1420 W (S1*)
1500 W (S3** 25%)
4000 min
approx. 50 l
approx. 10 bar
approx. 220 l/min
approx. 130 l/min
approx. 90 l/min
approx. 65 l/min
IP 20
1000 m
approx. 24.5 kg
73.43 dB
2.92 dB
pA
93.9 dB
wA
97 dB
wA
2.92 dB
wA
www.scheppach.com
WARNING
The noise emission values can vary from the
specified values during the actual use of the
power tool, depending on the type and the
manner in which the electric tool is used, and
in particular the type of workpiece being pro-
cessed.
Try to keep the stress as low as possible. For example:
-1
Limit working time. In doing so, all parts of the operating
cycle must be taken into account (such as times in
which the power tool is switched off or times in which it
is switched on, but is not running under a load).
7 Safety instructions
General power tool safety warnings
WARNING
Read all safety warnings, instructions, illus-
2 m
trations and specifications provided with this
power tool.
Failure to follow all instructions listed below may result
in electric shock, fire and/or serious injury.
Save all warnings and instructions for future
reference.
The term "power tool" in the warnings refers to your
mains-operated (corded) power tool or battery-operated
(cordless) power tool.
1) Work area safety
a) Keep your work area clean and well-lit. Cluttered or
dark areas invite accidents.
b) Do not operate power tools in explosive atmo-
spheres, such as in the presence of flammable liq-
uids, gases or dust. Power tools create sparks which
may ignite the dust or fumes.
c) Keep children and bystanders away while operat-
ing a power tool. Distractions can cause you to lose
control.
2) Electrical safety
a) Power tool plugs must match the outlet. Never
modify the plug in any way. Do not use any adapt-
er plugs with earthed (grounded) power tools. Un-
modified plugs and matching outlets will reduce risk of
electric shock.
b) Avoid body contact with earthed or grounded sur-
faces, such as pipes, radiators, ranges and refrig-
erators. There is an increased risk of electric shock if
your body is earthed or grounded.
c) Do not expose power tools to rain or wet condi-
tions. Water entering a power tool will increase the
risk of electric shock.
d) Do not abuse the cord. Never use the cord for car-
rying, pulling or unplugging the power tool. Keep
cord away from heat, oil, sharp edges or moving
parts. Damaged or entangled cords increase the risk
of electric shock.
