Starting locomotive operation
GB
Unwrap model: Take out the model cautiously
with foil (fig. 1).
Operating instructions: Before use is advisable
to let the loco go around about 30 minutes for-
wards an 30 minutes backwards without load, to
obtain an optomal circuit and best tractive power.
The smallest radius this model should run is R2 of
the ROCO track system (R2 = 358 mm).
Your locomotive will run smoothly on clean tracks
only. For this purpose we recommend using item
no. 46400, Roco track cleaning van, or item
no. 10002, Roco track cleaning rubber, for
remo-ving heavy dirt.
This model is not equipped for real overhead ope-
ration!
Maintenance of the model
GB
To enjoy your model for a long time, it is neces-
ary to service it regulary (i.e. after it has been in
ope-ration for approximately 30 hours).
1. Cleaning of wheel contacts: Wheel contacts
easily get dirty on tracks which are not entirely cle-
an. Use a small brush to remove dirt from spots
marked in fig. 4. Prior to cleaning the contacts dis-
mantle the bogie.
2. Lubrication: Apply tiny oil drops to spots
marked in fig. 6. Prior to lubrication dismantle lo-
comotive (fig. 3). We recommend using item no.
10906, Roco oiler. For lubrication the gearparts
(e.g. cogwheels, worm) we whould recommended
our Roco special grease (item no. 10905).
Attention: Please do not oil these parts when
using our grease.
10
Fittings: Operation is possible with different
couplings (fig. 2). We recommend using the Roco
close coupling.In the enclosed accessory bag you
will find small kits to be fitted on your locomotive.
Please mount them cautiously.
Attention! Use glue only if indicated (fig. 2).
Running in digital mode:
Remove the jumper from the interface.
Finally put the plug of the chip into the interface as
shown in fig. 5.
A.C. operation: see fig. 9
3. Change of traction tyre: Remove the gear
cover. Take out wheel set and remove tracti-
on tyre using a pin or a fine screwdriver (fig. 7).
When pressing on the new traction tyre please
avoid twisting it.
4. Carbon Brush Changing: First remove loco
body (fig. 3), and then the motor (fig. 8).
Assembly: During assembly please take care of
correct position of contacts.
Decoder interface
GPIO/C
Zugbus-Clock / GPIO/B
Masse GND
Front light - Drivers cab 1
V (+)
Twist protection
Front light - Drivers cab 2
Speaker A
Speaker B
Aux. 4 (F4) red Taillight, right, Drivers cab 2
Aux. 6 (F6) red Taillight, right, Drivers cab 1
1
2
Aux. 3 (F3) red Taillight, left, Drivers cab 2
P
16
lux
3
4
GPIO/A / Zugbus-Data
5
6
DC (+) Elko
7
8
Engine right (+)
9
10
Engine left (-)
12
Track/Pick up right
13
14
Track/Pick up left
15
16
Aux. 1 (F1)
Front light - Drivers cab 1
17
18
Aux. 2 (F2)
Front light - Drivers cab 2
19
20
Aux. 5 (F5) red Taillight, left, Drivers cab 1
21
22
Aux. 7 (F7)
3
