Warranty

You have purchased an original IKA
engineering and quality standards.
In accordance with IKA warranty conditions, the warranty period is 24 months. For
®
claims under the warranty please contact your local dealer. You may also send the
machine direct to our works, enclosing the delivery invoice and giving reasons for
the claim. You will be liable for freight costs.
The warranty does not cover wearing parts, nor does it apply to faults resulting from
improper use or insufficient care and maintenance contrary to the instructions in this
operating manual.

Technical data

Design voltage VAC 220-230±10%
or VAC 100-115±10%
Design frequency Hz
Power consumption W
Output power W
Motor speed, idle rpm 28 000
Motor speed, under load rpm 25 000
Circumferal speed
Idle m/s 76
Under load m/s 53
Effective volume
Grinding container A 11.5 ml
Grinding container A 11.4 ml
Working time
Short-time operation (KB) min 1 / 10
Safety
Fuse on power board
220-230 V A
100-115 V A
laboratory machine which meets the highest
®
50/60
160
100
80
250
1 min. ON / 10 min OFF
Safety switch on the grinding container,
temperature limiter in the motor
8T Id.-No. 31 406 00
6.3 A circuit-breaker
Malfunction display
Drive
Parts in contact with product
Grinding beaker A 11.5 (80 ml)
Grinding beaker A 11.4 (250 ml)
Rotor shaft
Beater A 11.1
Cutter A 11.2
Beater A 11.3
Double beater A 11.6
Filling funnel A 11.7
Permitted ambient
temperature: °C
Permitted relative humidity %
Protection type to
DIN EN 60529
Protection class
Excess voltage category
Contamination level
Noise level dB
Operation at a m
Dimensions (W x D x H) mm 85 x 85 x 240
Weight kg
Subject to technical changes!
Orange-red glow lights, display of over-
temperature and grinding area not closed
Universal motor
stainless steel 1.4571
(outer shell fluoroplastic ETFE)
stainless steel 1.4571
(outer shell polycarbonate PC)
stainless steel 1.4571
stainless steel 1.4034
(hardness approx. 52 HRC)
stainless steel 1.4112
(hardness approx. 55 HRC)
stainless steel 1.4112, wolfram - carbide coated
(core hardness approx. 58 HRC, surface
hardness approx. 1500 HV)
titanium (plasma nitrited,
surface hardness 1200 HV)
stainless steel1.4571/PTFE
+5 to +40
80
IP 43
II
II
2
max. 85
max. 2000 above sea level terrestrial altitude
1.5
22
