8. Specifications

Modell
Amplifier power (rms/ peak)
EQ
Drivers
Enclosure
Sensitivity at 1W/1m
Max. sound pressure level
Audio frequency response
Projection angle (H x V)
Mixer inputs
Phantom power
Outputs
Connectors
Processor functions
Dimensions (W x H x D)
Weight
AC adapter / charger
Rechargeabel battery
Battery life (speech / music)
Options for EasyPort FP2plus
1. Automatic ducking function
2. 12 VDC output for a portable receiver or external audio
source
3. Balancing transformer for line input
4. Wireless-microphone audio output on XLR connector 19
5. Commercial half-rack format wireless receivers from AKG,
Shure, etc will be installed on request. (Wider receivers
cannot be installed!)
FP1
plus
40 W
Bass / Treble
1 x 8" and annular
Bass reflex
Multiplex, enameled black,
Plastic feet, carrying handle,
36 mm socket for stand,
Impact resistant metal grille
Acoustic foam
98 dB
114 dB
80 Hz to 19 kHz (-6dB)
80° x80°
Wired mic 1 kΩ
Wireless mic: internal, 10 kΩ
2 x line 10 kΩ
12 V
2 x line +3dB into 600 Ohm,
for recording or stacking
Mic input: 3-pin XLR
line inputs: RCA jacks
(stereo summed to mono)
line outputs: RCA jacks
Limiter w/Autosubsonic filter
240 x 341 x 251 mm
(9.4 x 13.4 x 10 in.)
6,5 kg (14.4 lbs.)
inc. battery and receiver
External charger
20VDC / 500mA
12 V, approx. 3,4 Ah
6 to 12 hours
Specifications subject to change without notice.
FP2
plus
40 W / 60 W
Bass / Treble
1 x 8" and annular
2-way Bass reflex
Multiplex, enameled black,
Plastic feet, carrying handle,
36mm socket for stand
Impact resistant metal grille
Acoustic foam
Threads for SHP2 stand adapter
100 dB
125 dB
65 Hz to 20 kHz (-6dB)
80° x80°
Wired mic 1 kΩ
Wireless mic: internal, 10 kΩ
2 x line 10 kΩ
12 V (48 V optional)
2 x line +3dB into 600 Ohm,
for recording or stacking
Mic input: 3-pin XLR
line inputs: RCA jacks
(stereo summed to mono)
line outputs: RCA jacks
Limiter w/Autosubsonic filter
Automatic proximity filter
240 x 510 x 270 mm
( 9.4 x 20 x 10.6 in.)
12 kg (27 lbs.)
inc. battery and receiver
230 VAC
1A MTR (5x20mm) fuse
12 V, approx. 7.2 Ah
8 to 20 hours
