6. Operating Notes

6.1 Optimum Placement

In order to ensure consistent coverage and intelligibility from the
first to the last row of the auditorium,
1. Place the loudspeaker as high as possible using a loudspeaker
stand.
2. Check that the loudspeaker is clearly visible from each seat or
standing room area and that the sound will not be diffracted by
people or objects.
To optimally align the FP2plus, you can use the optional SHP2
stand adapter.
1. Mount the loudspeaker on the stand adapter.
2. Place the stand adapter on the loudspeaker stand.
3. Extend the stand to its full length and aim the loudspeaker
down at the audience in the same way you would aim a spot-
light to cover the entire audience.

6.2 Avoiding Feedback

When using your EasyPort with a wired or wireles microphone,
acoustic feedback may occur so the loudspeaker would start whist-
ling or howling. To prevent feedback.
1. Make sure the talker will stand behind the loudspeaker in order
to prevent feedback
2. Make sure never to point the microphone element directly at
the loudspeaker.
3. Hold the handheld transmitter by the shaft. Be sure not to cover
the microphone element with your hand.
4. Should the loudspeaker start whistling or howling all the same
turn the volume control 9 or 12 down CCW to the point that
the feedback noise will stop.
6.3 Using a Wireless Microphone
How to operate a wireless microphone system depends on the
receiver installed and the type of transmitter and microphone
used. For detailed instructions refer to the manual that comes with
the installed receiver and the manufacturer's manual(s) for your
transmitter and microphone.

7. Cleaning

You can clean the loudspeaker enclosure with a moistened cloth.
Make sure that no liquid will penetrate into the case.
