Frontansicht
Do not touch
vapour and nozzle area!
C A U T I O N !
Extrem temperatures
(hot & cold)
Rückansicht
5
2: · Fluidschlauch
3: · Schlauchanschluß
4: · Netzkabel
5: · Anschluß für
Flüssig-CO
-Schlauch
2
3. Bezeichnung der Teile
7
This machine has been designed to be used with
original Look CRYO-FOG-fluid.
Use of other liquids will void the manufacturer's
warranty and can be dangerous to your health.
Never use cleaner or fragrances with this
machine!
For Low Pressure Liquid CO · Operating Pressure 20 - 25 bar · Read manual before use!
2
!!!!!!!!!
AFTER OPERATION
!!!!!!!!!
1. Close the valve at the CO
tank
2
230V~/50Hz/2200W
2. Exhaust the CO
remaining in the
2
hose (display: Co2 or DMX: Channel 3)
Serial no.
Made by OTTEC Technology GmbH for Look Solutions. Made in Germany.
1: · Nebelaustrittsöffnung
8
6
Analog
DMX 512
3
4
6: · DMX in/out
7: · Bedienfeld zum Einstellen
der DMX-Startadresse und
zur Regelung des Outputs
8: · Buchse für analogen Betrieb
7
