Linde E300 Gebrauchsanweisung Seite 12

3.2. FLOW SCHEME E300
EN
4
3
2
1
3.3. GENERAL INFORMATION
Information
Max. Weight [kg]
Length [mm]
Depth [mm]
Height [mm]
3.4. CONNECTION VALUES
Information
Process Inlet Connection
Vent Connection
3.5. PERFORMANCE VALUE
Information
Nominal flow
Inlet pressure (max.)
3.6. OPERATING CONDITIONS
Information
Temperature range
Relative humidity (max.)
E300R-300BC E300L-300BC
1,1 1,1
333 333
112 112
220 220
Value
N14F - NPT1/4 INCH FEMALE
0001 - plugged
Value
20 (Air)
300
Value
-20 till +60
98
Vent Out
PT
5
E300R-1000BC
1,2
1033
112
220
12/40
6
Process
1 – GAS CYLINDER
2 – COIL
3 – CHECK VALVE
4 – SHUT-OFF VALVE
(1 X IN, 3 X OUT)
5 – VENT VALVE
6 – GAUGE / PRESSURE
TRANSMITTER
E300L-1000BC
1,2
1033
112
220
Unit
m /h
3
bar
Unit
°C
%
