In Case Of Installation Method 7A & 7B - Renson Fixscreen 150 (F) Installationsanleitung

Fixscreen
en
3.2 • In case of installation method 7A & 7B
➊
➁
➀
Demount the cover plate from
the box. Place the cover plate
at a dry place. Undo the clip-
ping piece ➀ which is used
for closing the bottom of the
box. Unscrew the guiding
piece ➁ which is used for
guiding the bottom rail into
the box.
➍
Hold the fabric roller on both sides upwards and remove from
the box. Thanks to the Connect&Go you don't have to struggle
with the cable.
42
150 (F)
®
➋
Unscrew the fabric roller on
both sides
➌
➂ ➃ ➂
Push the fabric roller up on
both sides while pressing the
security cams ➂. Pull gently
the fabric roller out of the
box, holding both ends of
the box ➃.
Always perform
with 2 persons!
➎
Place the black protection
cap of the Connect&Go.
Only when the PVC
sliders are fully fixed, a
good connection with the
Connect&Go technology is
guaranteed.
