5 Product information

5.1 Type key

Example: Zeox FIRST-V 9004/A-75-2-S20_S6D6
Zeox FIRST
V
90
04
A
75
2
S20
S6D6
Variants of flanges and shaft orientations
Zeox FIRST V
S: Flange on suction side
D: Flange on discharge side
Standard: S3 D9, other configurations on request.
Installation and operating instructions Wilo-Zeox FIRST
Wilo pump code
V: vertical range
H: horizontal range
Nominal flow in m3/h
Number of impellers
Impeller type (only relevant for vertical range)
Nominal motor power in kW
Number of poles
Construction variants:
[...]: standard (mechanical seal)
L1: bronze impellers
S20: with gland packing
Variants of flanges and shaft orientations:
[...]: standard orientation
Further possible orientations,
see graphics under "Variants of flanges and shaft orientations" below
