1)
Introduction
The BExCS110-05D is a flameproof combined sounder /
beacon which is certified to the European Standards EN
60079-0:2006 and EN 60079-1:2007 and meets the
requirements of the ATEX directive 94/9/EC. The sounder
section produces loud audio warning signals and the beacon
section produces a synchronised visual warning signal. The
unit can be used in hazardous areas where potentially
flammable atmospheres may be present. Thirty-two different
first stage audio alarm sounds can be selected by internal
switches, and each one can be externally changed to a
second or third stage alarm sound (see tone table on Page
The sounder produces output levels in the 110dB(A)
5).
range and the beacon produces an output level of 5 joules.
The unit can be used in Zone 1 and Zone 2 areas with gases
in groups IIA and IIB and with Temperature Classifications of
T1, T2, T3 and T4.
2)
Marking
All units have a rating label, which carries the following
important information:-
BExCS110-05D
Unit Type No.
Input Voltage:
DC Units
AC Units
Ex d IIB T4 for Ta –50ºC to +70° C
Code:
KEMA 03ATEX2545X
Certificate No.
Epsilon x:
Gas Group and
Category:
CE Marking:
Notified Body No.
Warnings:
DO NOT OPEN WHEN AN EXPLOSIVE
GAS ATMOSPHERE IS PRESENT
COVER BOLTS CLASS A4-80
USE HEAT RESISTING CABLES AND
CABLEGLANDS (Rated 110ºC) AT
AMB. TEMPERATURES OVER 40ºC
Year of Construction /
Serial No.
3)
Type Approval Standards
The units have an EC Type examination certificate issued by
KEMA and have been approved to the following standards: -
Pfannenberg GmbH
·
Werner Witt-Straße 1
PDG-Doc-No.: 30080-004a
12V or 24V or 48V
230V or 115V
II 2G
0344
i.e. 10 / 1CS21000001
·
D-21035 Hamburg
INSTRUCTION MANUAL (ATEX)
BExCS110-05D
Flameproof Combined Sounder / Beacon
EN 60079-0 : 2006
EN 60079-1 : 2007
4)
Installation Requirements
The unit must be installed in accordance with the latest
issues of the relevant parts of the BS EN 60079
specifications or the equivalent IEC specifications –
Selection,
apparatus for use in potentially explosive atmospheres (other
than mining applications or explosive processing and
manufacture):-
BS EN 60079-14 : 2008
BS EN 60079-10 : 2003
The installation of the unit must also be in accordance with
any local codes that may apply and should only be carried
out by a competent electrical engineer who has the
necessary training.
5)
Zones, Gas Group, Category and Temperature
Classification
The BExCS110-05D unit has been certified Ex d IIB T4 for
Ta –50° C to +70° C. This means that the units can be
installed in locations with the following conditions: -
Area Classification:
Zone 1
Zone 2
Gas Groupings:
Equipment Category:
Temperature Classification:
Ambient Temperature Range:
·
Tel.: 040/7 34 12-0
·
Telefax:040/ 734 12-345
GB 1 / 6
General Requirements
Flameproof Enclosure 'd'
Installation
and
maintenance
Electrical Installations in Hazardous
Areas (other than mines)
Classification of Hazardous Areas
Explosive gas air mixture likely to occur in
normal operation.
Explosive gas air mixture not likely to occur,
and if it does, it will only exist for a short time.
Group IIA
Propane
Group IIB
Ethylene
2G
o
T1
400
C
o
T2
300
C
o
T3
200
C
o
T4
135
C
-50°C to +70°C
of
electrical
09/2010
