Offset Data type
Q5.0 Bool
Q5.1 Bool
Q5.2 Bool
Q5.3 Bool
Q5.4 Bool
Q5.5 Bool
Q5.6 Bool
Q5.7 Bool

7.1.3 Data of module 3

Offset Data type
IW7 Word

7.1.4 Data of module 4

Offset Data type
IW9 Word

7.1.5 Data of module 5

Offset Data type
IW11 Word

7.1.6 Data of module 6

Offset Data type
IW13 Word

7.2 Control from Profibus-Master

The instructions for the valve controlling of the master are accepted only in mode "DCS" of
SAM-1000_DP. For example to open the sample gas valve of analysis point 1 there has to be set Q1.0
"1". For closing this valve the output has to be set "0". All valves are controlled in this way. The last
sample gas valve remains opened, also without any control from master. This secures that the
analysis devices are provided with gas.
If the output Q0.0 "DCS disable mode local" is set, there will be possible no local operation. The
valves are controlled only by DCS.
From the offsets I4.0 and Q4.0 the free inputs and outputs of SAM-1000_DP are passed through. This
range is not predefined and is determined by the wiring at the SAM-1000_DP.
Product:
SAM-1000_DP
Assignment
Signal to digital output 26
Signal to digital output 27
Signal to digital output 28
Signal to digital output 29
Signal to digital output 30
Signal to digital output 31
Signal to digital output 32
Assignment
Actual value sample gas pressure
Assignment
Signal from analog input 2
Assignment
Signal from analog input 3
Assignment
Signal from analog input 4
