5.2 Mechanical design

The SAM-1000_DP is designed as a 19" slide-in module for installation in a 19" rack or a 19" cabinet. The
height is 6 HU.
• Housing with screwed on front panel
• Control unit
• Valve block
• Outlet block
• Depending on the configuration of the bulkhead connector fittings, the flow meters
and the pressure regulator

5.3 Dimensional drawing

The following drawing shows the necessary space required:
(Depth without flowmeter and rear screw connections)
