MWR-KIT

Technical Data

Environmental
• Indoor Use ONLY
• Pollution Degree 2
• Room Temperature: 5 °C to 40 °C (41 °F to 104 °F)
• Maximum relative humidity 80% for temperature up to
31 °C (88 °F) decreasing linearly to 50% relative humid-
ity at 40 °C (104 °F)
• Altitude: Up to 2000 m

Technical specification

All MTRw, MWR-TA (torque - angle) and MWR-S (signal)
models are supported.
Memory capacity:
Radio distance up to:
Rated input voltage:
Rated input power:
Rated current:
Radio range distance can be influenced by various factors, in-
cluding:
• Antenna characteristics: placement of antennas can affect
range.
• Environmental conditions: weather, terrain, obstacles,
metal parts, can impact signal strength and range.
• Interference: other electronic devices and signals can
cause interference, reducing the effective range.
Declarations

EU DECLARATION OF CONFORMITY

We, Atlas Copco Industrial Technique AB, SE-105 23
STOCKHOLM SWEDEN, declare under our sole responsi-
bility that the product (with name, type and serial number, see
front page) is in conformity with the following Legislation(s):
2011/65/EU (RoHS), 2014/53/EU (RED), 2015/863/EU
(RoHS amendment), RED Delegated Act (EU) 2022/30/EU
Harmonized standards applied:
EN 300220-1 v3.1.1, EN 300220-2 v3.2.1, EN 301489-1
v2.2.3, EN 301489-3 v2.1.1, EN 50581:2012, EN
55032:2015 + AC:2016 + A11:2020 + A1:2020, EN
55035:2017 + A11:2020, EN 61000-3-2:2019 + A1:2021,
EN 61000-3-3:2013 + A1:2019 + A2:2021, EN 61010-1, EN
62311:2008, EN 18031-1:2024
Authorities can request relevant technical information from:
Product Compliance Engineer, Atlas Copco BLM srl., Via
Guglielmo Pepe 11 - 20037 Paderno Dugnano - Milano - Italy
Stockholm, 1 November 2025
Lars Eklöf, Managing Director
16 GB
20 m (MTRwrench); 5 m
(MWR)
24 Vdc
1 W
0.180 A
© Atlas Copco Industrial Technique AB - 9839 1723 00
Signature of issuer
Radio equipment directive (RED)
The tool may be operated in the following countries:
The abbreviations of the member States concerned are: Aus-
tria (AT), Belgium (BE), Bulgaria (BG), Switzerland (CH),
Cyprus (CY), Czech Republic (CZ), Germany (DE), Denmark
(DK), Estonia (EE), Greece (EL), Spain (ES), Finland (FI),
France (FR), Croatia (HR), Hungary (HU), Ireland (IE), Italy
(IT), Iceland (IS), Liechtenstein (LI), Lithuania (LT), Luxem-
bourg (LU), Latvia (LV), Malta (MT), Netherlands (NL),
Norway (NO), Poland (PL), Portugal (PT), Romania (RO),
Sweden (SE), Slovenia (SI), Slovakia (SK), Turkey (TR) and
the United Kingdom (UK).
WEEE
Information concerning Waste of Electrical and Electronic
Equipment (WEEE):
This product and its information, meets the requirements of
the WEEE directive/regulations (2012/19/EU), and must be
handled in compliance with the directive/regulations.
The product is marked with the following symbol:
Products marked with a crossed-out wheeled bin symbol and
a single black bar underneath, contain parts that must be han-
dled in compliance with the WEEE directive/regulations. The
entire product, or the WEEE parts, can be sent to your "Cus-
tomer Center" for handling.
UK DECLARATION OF CONFORMITY
We, Atlas Copco Industrial Technique AB,
SE-105 23 STOCKHOLM SWEDEN, declare
under our sole responsibility that the product
(with name, type and serial number, see front
page) is in conformity with the following UK
Regulation(s):
S.I. 2017/1206
Safety Information
3
